Feeding system

Application: Potting; Sealing; filling; insulation; cooling; adhesive; coating

MPS-230 Two-component Feeding System

The variable ratio gear pump feeding can accurately measure, mix and distribute medium and low viscosity materials for bonding, sealing, packaging and coating applications. It adopts volumetric technology and compact modular structure design.

Features:

1. Intuitive user interface and modular processing and control system;

2. Accuracy, reliability and durability;

3. Servo motor drive - achieve variable proportion adjustment;

4. Real-time monitoring conveying process and real-time feedback flow information;

5. Precision gear pump - ultra-high wear resistance and ultra-long service life;

6. Flexible configuration size - achieve a variety of proportioning and application;

7. Digital control - easy to use and reduce downtime;

8. High and low liquid level detection - when the lack of material and full material can prompt and alarm;

9. Optional ingredients tank heating, stirring, vacuum eliminate bubble and static and dynamic mixing functions.

ATC-100 Two-component feeding system

It is suitable for small batch production or laboratory verification applications. It integrates screw metering pump and gear metering pump, can meet most of the filling and sealing application needs, but also optional stirring, heating, eliminate bubble and other raw material functions.

Features:

1. It adopts piston volumetric design;

2. Piston stroke, real-time monitoring；

3. Cylinder drive - low failure rate;

4. Easy maintenance - low maintenance cost;

5. Ceramic metering cylinder block - ultra-high wear resistance and long service life;

6. Flexible configuration size - achieve a variety of proportioning and application;

7. Digital control - easy to use and reduce downtime;

8. High and low liquid level detection - when the lack of material and full material can prompt and alarm;

9. Optional ingredients tank heating, stirring, vacuum eliminate bubble and static and dynamic mixing functions.

C61 High Viscosity Feeding System

Features:

1. Relying on innovative design and advanced glue pump and air motor technology, it reliably delivers single-component sealants, adhesives and other high-viscosity materials from the barrel to metering and distribution systems.

2. It is suitable for 5 gallon packing size;

3. It is suitable for medium to high viscosity materials.

FS-02 Two-component feeding system

Features:

1. It is suitable for multi-proportion pneumatic two-component feed;

2. It is suitable for 400ml fixed ratio double glue bucket;

3. Low level detection function - when the lack of material,it can alarm and prompt to replace the rubber bucket.

MV-06 Two-component precision measurement valve

Two-component precision measurement valve is designed for continuous dispensing and potting applications, specially dealing with materials from low viscosity to high viscosity, which belongs to the external meshing position-type gear metering valve; It can be used for complex shape work, but also for the convenience of the operator. It has high flexibility, which can be applied to different parts and different amounts of glue.

Features:

1. Maintain high precision and stability under the condition of temperature, viscosity and pressure change;

2. Accurate measurement - high precision machining and accurate control of closed loop loop ensure its accuracy；

3. Flow stability - the unique design makes the flow output no fluctuation;

4. Simple structure - only three moving parts and after hardening treatment, which gives it good wear resistance.

Two-component valve

Application: Epoxy resin, silicone resin, Polyurethane resin, Thermal conductive material.

DV2 Static distribution valve

DV-20 valve is a switch valve designed for two-component dispensing and potting. It is controlled by compressed air, the switch action is sensitive and fast, is an indispensable part of two-component dispensing and potting; It is suitable for epoxy resin, silicone resin, polyurethane and thermal conductive materials such as two component glue; It uses a balanced spool design to provide a suction effect.

Features:

1. Materials are separated separately before mixing to avoid cross contamination;

2. The stainless steel valve can be used for corrosive materials;

3. It can achieve a maximum flow rate of 4L/ min;

4. Switch function - metering pump according to the correct A:B proportion control metering;

5. It can choose NBR, PTFE, UHMWPE, which is suitable for different chemical formulations and grinding conditions.

SDV-20 Two-component liquid valve

SDV-20 valve is a switch valve designed for two-component dispensing and potting. It is controlled by compressed air, the switch action is sensitive and fast, is an indispensable part of two-component dispensing and potting; It is suitable for epoxy resin, silicone resin, polyurethane and thermal conductive materials such as two component glue; It uses a balanced spool design to provide a suction effect.

Features:

1.Materials are separated separately before mixing to avoid cross contamination;

2.The stainless steel valve can be used for corrosive materials;

3.It can achieve a maximum flow rate of 4L/ min;

4.Switch function - metering pump according to the correct A:B proportion control metering;

5.It can choose NBR, PTFE, UHMWPE, which is suitable for different chemical formulations and grinding conditions.

DDV-20 Dynamic mixed glue valve

DDV-20 dynamic mixed glue valve is suitable for glue with low to medium viscosity and different proportions. The servo motor drives the mixing blade to rotate at high speed in the mixing chamber to mix out glue, which has very low back pressure. Especially suitable for large viscosity difference of two component glue or space limited occasions.

Features:

1. Servo drive - high repetition accuracy;

2. It is suitable for viscosity difference large glue;

3. It is suitable for ratio ratio of glue;

4. separately before mixing to avoid cross contamination;

5. Stainless steel valve can be used for corrosive materials;

6. Fast stirring speed - the maximum speed can be 1900rpm;

7. Compact design for easy automated integration.
