1. Widely applicable - Diversified light source combination, mercury lamp, electrodeless lamp tube/LED, UV, can meet a variety of curing methods;
2. Low energy consumption - Customized UV lamp and advanced frequency conversion power supply technology can effectively ensure the stable output of UV capacity and greatly reduce energy consumption;
3. Adjustable power - The lamp management can work continuously for 2000 hours.
| Specifications | UV-1 | UV-2 | UV-3 | |
| Transmission type | Conveying component height (mm) | ±100 | ||
Conveyor chain height (mm) | 900±20 | |||
Conveyor speed (m/min) | 0.3-3.2 | |||
Conveyor direction | Left→right (standard) □ right→left□ | |||
| Maximum load | 4kg/m evenly distributed | |||
| Factory requirements | Dimensions(mm) | L1535×W1100×H1600 | ||
| Weight (kg) | 400 | 400 | 410 | |
| Power supply | 380V, 50Hz, three-phase five-wire system | |||
| Rated power(kw) | 7.0 | 7.0 | 13.0 | |
Number of light groups | One set above the track | Two groups above the track | One set on the top and bottom of the track | |
