Dimension (mm)

L1120×W740×H760

L1200×W740×H146

Weight (kg)

100

130

Control

Industrial personal computer + motion control card

Software

Anda control software + windows system

Programming

Visual programming

Number of spindles

X、Y1、Y2、Z

Spindle drive

Servo motor + module

Working area (mm)

X1 X2: 260;  Y1 Y2: 260;  Z: 100

Quantity of rubber valve

1 (standard configuration)

Max. Moving speed (mm/s)

800

Repeatability (mm)

± 0.025

Coating capacity (cc)

30

Valve nozzle

cleaning device

Vacuum cleaning

Equipment alarm

Menu + sound and light alarm

Coating inspection

Automatic detection

Power supply

220V 50/60Hz

Required air pressure (Mpa)

≥ 0.65

Safety standards

CE

Rated power (kw)

1.3

1.5

Standard function

CCD visual positioning

Electrostatic interface

232 scanner socket
