It interacts with AGV through optical communication sensors for signal exchange.
The lifting mechanism is made from integrated cast iron for enhanced stability.
The equipment supports automatic docking with AGV for loading and unloading trays.
It operates in both manual and automatic modes.
It has a built-in 2.4G WiFi communication module.
It can interface with MES systems.
The equipment features a welded steel frame with aluminum profile connections.
It employs PLC and touchscreen control, with audible and visual alarms for faults and a menu display.
The conveyor uses an antistatic direct-drive chain for material transport.
The tray width is 330mm, compatible with boards less than 330mm in width, and can hold a maximum of 50 sheets per full tray (customizable).
The board width is adjustable within the range of 50–330mm.
Overall Dimensions (mm) | L1450×W850×H1600（mm） | Conveyor Chain Height (mm) | 900±20mm |
Supply Voltage | AC220V 50/60HZ | Conveyor Speed (m/min) | 0.5~0.8m/min |
Drive | Deceleration Motor + Chain | Conveying Direction | L ← → R |
Control Method | Button + Control Panel | Air Pressure (MPa) | ≥0.6MPa |
Rated Power (KW) | 0.5KW | Conveying Typ | Direct-Drive Chain |
