It interacts with AGV through optical communication sensors for signal exchange.
The lifting mechanism is made from integrated cast iron for enhanced stability.
The equipment supports automatic docking with AGV for loading and unloading trays.
It operates in both manual and automatic modes.
It has a built-in 2.4G WiFi communication module.
It can interface with MES systems.
Overall Dimensions (mm) | L1800×W850×H1600（mm） | Conveyor Chain Height (mm) | 900±20mm |
Supply Voltage | AC220V 50/60HZ | Conveyor Speed (m/min) | 0.5~0.8m/min |
Drive | Deceleration Motor + Chain | Conveying Direction | L ← → R |
Control Method | Button + Control Panel | Air Pressure (MPa) | ≥0.6MPa |
Rated Power (KW) | 0.5KW | Conveying Type | Direct-Drive Chain |
